TY2x80 130hp Hydraulic Cable Tensioner Max Tension 2x100kN / 1x200kN

Yixing Boyu Electric Power Machinery Co.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TY2x80 130hp Hydraulic Cable Tensioner Max Tension 2x100kN / 1x200kN

  • 1
  • 2
  • 3
  • 4

Brand Name : Boyu

Model Number : TY2x80-28

Certification : ISO9001

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 100sets/month.

Delivery Time : 15~25 days

Packaging Details : Carton

Max tension : 2x100kN / 1x200kN

Bull-wheel diameter : 1850mm

Overall dimension (length*width*height) : 5520×2280×2850mm

Rated tension : 2x80kN / 1x160kN

Diesel : 97kw(130hp)

Total weight : 10000kg

Groove number : 2x6

Engine : Cummins

Pull at max speed : 2x40kN/1x80kN

Max reverse pulling speed : 3km/h

Contact Now

TY2x80 130hp Hydraulic Cable Tensioner Max Tension: 2x100kN / 1x200kN

The machine can tension the 1000mm2 double-beam conductor on a flat platform; in addition, it can be used to pull OPGW or ADSS cable and 500kV traction rope in various terrains.

Performance
Max tension 2x100kN / 1x200kN
Rated tension 2x80kN / 1x160kN
Speed at max tension 2.5km/h
Max feeding speed 5km/h
Pull at max speed 2x40kN/1x80kN
Max reverse pulling force 2x40kN/1x80kN
Max reverse pulling speed 3km/h

Characteristics
Bull-wheel diameter 1850mm
Groove number 2x6
Max conductor diameter 48.75mm
Total weight 10000kg
Overall dimension (length*width*height) 5520×2280×2850mm

Main configuration
Engine Cummins
Hydraulic pump German Rexroth/Dnish Danfoss
Main motor German Rexroth/French Leduc
Speed reducer German Rexroth
Hydraulic meter German
Operating handle German Rexroth

Engine
Diesel 97kw(130hp)
Cooling system water
Electrical system 24V

TY2x80 130hp Hydraulic Cable Tensioner Max Tension 2x100kN / 1x200kN

Company

TY2x80 130hp Hydraulic Cable Tensioner Max Tension 2x100kN / 1x200kN

Company Profile
  • Our company is located in Yixing City, Jiangsu Province with a total area of ​​42,800 square meters and more than 160 employees.
  • Our company is a high-tech enterprise in Jiangsu Province and has six patents, two of which are invention patents.

Our company has formed four series of products:

  1. Power construction tools
  2. Non-metallic galvanized production equipment (obtained high-tech products)
  3. CNC machine tools
  4. Low-voltage unpowered electric arc furnace compensation system

Our company is a Chinese high-tech enterprise with over 27 years of production experience.

We are a company specializing in the research and development, manufacturing and sales of various transmission line engineering machinery such as hydraulic transmission systems.

History

Our company was established in 1994

Our company passed ISO9001 certification in 2001 and obtained AAA certificate at the same time

In 2006, it was awarded the contract and trustworthy enterprise in Wuxi City, and the famous brand product in Wuxi City in the same year

In 2007, won the title of Jiangsu Province High-tech Enterprise, and in the same year won the Jiangsu Province Famous Brand Product

In 2009, won a major achievement award in Wuxi City

In 2010, Boyu cooperated with the famous German Caesars company and founded the Boset brand

Our company obtained the National Science and Technology Innovation Program Project in 2010.

As of November 8, 2010, Boyu has successfully sold nearly 4,000 sets of pullers and tensioning equipment (excluding mobile ground grinding). Our products sell well in Sudan, Myanmar, India, Kenya, Pakistan, Mexico, Angola, Germany.
